在 Android 應用程式中加入 Flutter 螢幕

本指南說明如何在現有的 Android 應用程式中加入單一 Flutter 螢幕。Flutter 螢幕可以作為一般、不透明的螢幕加入，也可以作為可透視的半透明螢幕加入。本指南將說明這兩種方式。

Flutter 提供了 FlutterActivity，可在 Android 應用程式中顯示 Flutter 體驗。和其他 Activity 一樣，FlutterActivity 必須註冊在你的 AndroidManifest.xml 中。請在 AndroidManifest.xml 檔案的 application 標籤下方加入以下 XML：

<activity
  android:name="io.flutter.embedding.android.FlutterActivity"
  android:theme="@style/LaunchTheme"
  android:configChanges="orientation|keyboardHidden|keyboard|screenSize|locale|layoutDirection|fontScale|screenLayout|density|uiMode"
  android:hardwareAccelerated="true"
  android:windowSoftInputMode="adjustResize"
  />

@style/LaunchTheme 的參考可以替換為任何你想要套用到 FlutterActivity 的 Android 主題（theme）。 主題的選擇會決定應用於 Android 系統 chrome（如 Android 導覽列）的顏色，以及在 Flutter UI 首次渲染前，FlutterActivity 的背景顏色。

在你的 manifest 檔案中註冊好 FlutterActivity 之後， 你可以在應用程式中任何你想要的地方，加入程式碼來啟動 FlutterActivity。以下範例展示了 從 OnClickListener 啟動 FlutterActivity 的方式。

MyButton(onClick = {
    startActivity(
        FlutterActivity.createDefaultIntent(this)
    )
})

@Composable
fun MyButton(onClick: () -> Unit) {
    Button(onClick = onClick) {
        Text("Launch Flutter!")
    }
}

myButton.setOnClickListener {
  startActivity(
    FlutterActivity.createDefaultIntent(this)
  )
}

myButton.setOnClickListener(new OnClickListener() {
  @Override
  public void onClick(View v) {
    startActivity(
      FlutterActivity.createDefaultIntent(currentActivity)
    );
  }
});

前述範例假設你的 Dart 進入點（entrypoint）為 main()，且初始的 Flutter 路由為 /。Dart 進入點無法透過 Intent 進行變更，但初始路由可以使用 Intent 來修改。以下範例說明如何啟動一個 FlutterActivity，並在 Flutter 中初始渲染自訂路由。

MyButton(onClick = {
  startActivity(
    FlutterActivity
      .withNewEngine()
      .initialRoute("/my_route")
      .build(this)
  )
})

@Composable
fun MyButton(onClick: () -> Unit) {
    Button(onClick = onClick) {
        Text("Launch Flutter!")
    }
}

myButton.setOnClickListener {
  startActivity(
    FlutterActivity
      .withNewEngine()
      .initialRoute("/my_route")
      .build(this)
  )
}

myButton.addOnClickListener(new OnClickListener() {
  @Override
  public void onClick(View v) {
    startActivity(
      FlutterActivity
        .withNewEngine()
        .initialRoute("/my_route")
        .build(currentActivity)
      );
  }
});

將 "/my_route" 替換為你想要的初始路由。

使用 withNewEngine() 工廠方法會設定一個 FlutterActivity，該物件會在內部自行建立一個 FlutterEngine 實例。這樣會帶來不小的初始化時間。另一種做法是指示 FlutterActivity 使用預先加載並快取的 FlutterEngine，這樣可以將 Flutter 的初始化時間降到最低。接下來將說明這種做法。

每個 FlutterActivity 預設都會建立自己的 FlutterEngine。每個 FlutterEngine 都需要一定的預熱時間。這表示啟動標準的 FlutterActivity 時，在你的 Flutter 體驗顯示出來前會有短暫的延遲。為了減少這個延遲，你可以在進入 FlutterActivity 之前先預熱一個 FlutterEngine，然後直接使用這個預熱好的 FlutterEngine。

要預熱一個 FlutterEngine，請在你的應用程式中找到合適的位置來實例化 FlutterEngine。以下範例會在 Application 類別中隨機預熱一個 FlutterEngine：

class MyApplication : Application() {
  lateinit var flutterEngine : FlutterEngine

  override fun onCreate() {
    super.onCreate()

    // Instantiate a FlutterEngine.
    flutterEngine = FlutterEngine(this)

    // Start executing Dart code to pre-warm the FlutterEngine.
    flutterEngine.dartExecutor.executeDartEntrypoint(
      DartExecutor.DartEntrypoint.createDefault()
    )

    // Cache the FlutterEngine to be used by FlutterActivity.
    FlutterEngineCache
      .getInstance()
      .put("my_engine_id", flutterEngine)
  }
}

public class MyApplication extends Application {
  public FlutterEngine flutterEngine;

  @Override
  public void onCreate() {
    super.onCreate();
    // Instantiate a FlutterEngine.
    flutterEngine = new FlutterEngine(this);

    // Start executing Dart code to pre-warm the FlutterEngine.
    flutterEngine.getDartExecutor().executeDartEntrypoint(
      DartEntrypoint.createDefault()
    );

    // Cache the FlutterEngine to be used by FlutterActivity.
    FlutterEngineCache
      .getInstance()
      .put("my_engine_id", flutterEngine);
  }
}

傳遞給 FlutterEngineCache 的 ID 可以是任何你想要的值。 請確保你在任何需要使用快取 FlutterEngine 的 FlutterActivity 或 FlutterFragment 中傳遞相同的 ID。 接下來會說明如何將 FlutterActivity 與已快取的 FlutterEngine 搭配使用。

有了預先啟動並快取的 FlutterEngine 之後，你現在需要 指示你的 FlutterActivity 使用這個快取的 FlutterEngine，而不是建立新的實例。 為了達成這個目的，請使用 FlutterActivity 的 withCachedEngine() builder：

myButton.setOnClickListener {
  startActivity(
    FlutterActivity
      .withCachedEngine("my_engine_id")
      .build(this)
  )
}

myButton.addOnClickListener(new OnClickListener() {
  @Override
  public void onClick(View v) {
    startActivity(
      FlutterActivity
        .withCachedEngine("my_engine_id")
        .build(currentActivity)
      );
  }
});

當你使用 withCachedEngine() 工廠方法時， 請傳入你在快取目標 FlutterEngine 時所使用的相同 ID。

現在，當你啟動 FlutterActivity 時， 顯示 Flutter 內容的延遲會大幅減少。

The concept of an initial route is available when configuring a FlutterActivity or a FlutterFragment with a new FlutterEngine. However, FlutterActivity and FlutterFragment don't offer the concept of an initial route when using a cached engine. This is because a cached engine is expected to already be running Dart code, which means it's too late to configure the initial route.

Developers that would like their cached engine to begin with a custom initial route can configure their cached FlutterEngine to use a custom initial route just before executing the Dart entrypoint. The following example demonstrates the use of an initial route with a cached engine:

class MyApplication : Application() {
  lateinit var flutterEngine : FlutterEngine
  override fun onCreate() {
    super.onCreate()
    // Instantiate a FlutterEngine.
    flutterEngine = FlutterEngine(this)
    // Configure an initial route.
    flutterEngine.navigationChannel.setInitialRoute("your/route/here");
    // Start executing Dart code to pre-warm the FlutterEngine.
    flutterEngine.dartExecutor.executeDartEntrypoint(
      DartExecutor.DartEntrypoint.createDefault()
    )
    // Cache the FlutterEngine to be used by FlutterActivity or FlutterFragment.
    FlutterEngineCache
      .getInstance()
      .put("my_engine_id", flutterEngine)
  }
}

public class MyApplication extends Application {
  @Override
  public void onCreate() {
    super.onCreate();
    // Instantiate a FlutterEngine.
    flutterEngine = new FlutterEngine(this);
    // Configure an initial route.
    flutterEngine.getNavigationChannel().setInitialRoute("your/route/here");
    // Start executing Dart code to pre-warm the FlutterEngine.
    flutterEngine.getDartExecutor().executeDartEntrypoint(
      DartEntrypoint.createDefault()
    );
    // Cache the FlutterEngine to be used by FlutterActivity or FlutterFragment.
    FlutterEngineCache
      .getInstance()
      .put("my_engine_id", flutterEngine);
  }
}

By setting the initial route of the navigation channel, the associated FlutterEngine displays the desired route upon initial execution of the runApp() Dart function.

Changing the initial route property of the navigation channel after the initial execution of runApp() has no effect. Developers who would like to use the same FlutterEngine between different Activitys and Fragments and switch the route between those displays need to set up a method channel and explicitly instruct their Dart code to change Navigator routes.

大多數全螢幕的 Flutter 體驗都是不透明的。 然而，有些應用程式希望部署看起來像模態視窗（modal）的 Flutter 螢幕， 例如對話框（dialog）或底部彈出視窗（bottom sheet）。 Flutter 原生支援半透明的 FlutterActivity。

若要讓你的 FlutterActivity 具有半透明效果， 請在建立與啟動 FlutterActivity 的一般流程中進行以下修改。

Android 要求具有半透明背景的 Activity 必須指定特殊的主題屬性。 請建立或更新一個 Android 主題，並加入以下屬性：

<style name="MyTheme" parent="@style/MyParentTheme">
  <item name="android:windowIsTranslucent">true</item>
</style>

然後，將半透明主題（translucent theme）套用到你的 FlutterActivity。

<activity
  android:name="io.flutter.embedding.android.FlutterActivity"
  android:theme="@style/MyTheme"
  android:configChanges="orientation|keyboardHidden|keyboard|screenSize|locale|layoutDirection|fontScale|screenLayout|density|uiMode"
  android:hardwareAccelerated="true"
  android:windowSoftInputMode="adjustResize"
  />

您的 FlutterActivity 現在已支援透明度（translucency）。 接下來，您需要以明確支援透明度的方式啟動您的 FlutterActivity。

若要以透明背景啟動您的 FlutterActivity， 請將適當的 BackgroundMode 傳遞給 IntentBuilder：

// Using a new FlutterEngine.
startActivity(
  FlutterActivity
    .withNewEngine()
    .backgroundMode(FlutterActivityLaunchConfigs.BackgroundMode.transparent)
    .build(this)
);

// Using a cached FlutterEngine.
startActivity(
  FlutterActivity
    .withCachedEngine("my_engine_id")
    .backgroundMode(FlutterActivityLaunchConfigs.BackgroundMode.transparent)
    .build(this)
);

// Using a new FlutterEngine.
startActivity(
  FlutterActivity
    .withNewEngine()
    .backgroundMode(FlutterActivityLaunchConfigs.BackgroundMode.transparent)
    .build(context)
);

// Using a cached FlutterEngine.
startActivity(
  FlutterActivity
    .withCachedEngine("my_engine_id")
    .backgroundMode(FlutterActivityLaunchConfigs.BackgroundMode.transparent)
    .build(context)
);

你現在已經擁有一個具有透明背景的 FlutterActivity。
